| device application | Distribution |
|---|---|
| range | Acti 9 |
| product name | Acti 9 iK60 |
| product or component type | Miniature circuit-breaker |
| device short name | IK60N |
| poles description | 1P |
| number of protected poles | 1 |
| [In] rated current | 32 A at 30 °C |
| network type | AC |
| trip unit technology | Thermal-magnetic |
| curve code | C |
| breaking capacity | 4500 A Icn conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz |
| suitability for isolation | Yes conforming to EN/IEC 60898-1 |
| standards | EN/IEC 60898-1 |
| product certifications | Aenor |
| network frequency | 50/60 Hz |
|---|---|
| magnetic tripping limit | 5...10 x In |
| [Ics] rated service breaking capacity | 4500 A 100 % x Icu conforming to EN/IEC 60898-1 - 230 V AC 50/60 Hz |
| limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 440 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to EN/IEC 60898-1 |
| control type | Toggle |
| local signalling | ON/OFF indication |
| mounting mode | Clip-on |
| mounting support | DIN rail |
| 9 mm pitches | 2 |
| height | 85 mm |
| width | 18 mm |
| depth | 78.5 mm |
| product weight | 100 g |
| colour | White |
| mechanical durability | 20000 cycles |
| electrical durability | 10000 cycles |
| locking options description | Padlocking device |
| connections - terminals | Tunnel type terminal, top or bottom rigid wire(s) 1...25 mm² max |
| wire stripping length | 14 mm top or bottom |
| tightening torque | 2 N.m top or bottom |
| earth-leakage protection | Without |
| IP degree of protection | IP20 conforming to IEC 60529 |
|---|---|
| pollution degree | 2 conforming to EN/IEC 60898-1 |
| overvoltage category | III |
| ambient air temperature for operation | -25...60 °C |
| ambient air temperature for storage | -40...85 °C |
